The PXC1191 is a high-performance 18-slot PXI Express chassis featuring PCI Express 3.0 technology, delivering a system bandwidth of 24 GB/s for high-throughput, point-to-point data transfer applications. All peripheral slots support up to 8 GB/s bandwidth. Additionally, the chassis provides a total power of 1170W, with a per-slot cooling capacity of 50W/82W, ensuring a higher power budget for high-performance PXI modules.

The PXI Express timing and synchronization features offer high clock accuracy along with external clock and trigger routing capabilities.

The PXC1191 is equipped with an intelligent monitoring system that tracks and reports chassis status, including fan speed, system voltage, and internal temperature. Remote monitoring and control can be achieved via an Ethernet port.
