DMM4365

The DMM4365 is a 6½-digit digital multimeter module based on the PXI bus. It can perform measurements of AC/DC voltage, AC/DC current, 2-wire resistance, 4-wire resistance, frequency, and other signal types. It features automatic range selection and overload protection. When paired with matrix modules (2-wire, 4-wire) or multiplexer modules, a single DMM4365 can measure signals such as current, resistance, and frequency across multiple channels.

Technical Parameters

Product Model	DMM4365
Resolution	6½-bit
Measurement Mode	DC/AC voltage, DC/AC current, 2-wire resistance, 4-wire resistance, frequency, period
Voltage Measurement Range	DC -300V~300V AC 300V RMS
AC/DC Voltage Range	200mV, 2V, 20V, 200V, 300V, Auto
Current Measurement Range	DC -3A~3A AC 3A RMS
DC Current Range	2mA, 20mA, 200mA, 2A, 3A
AC Current Range	20mA, 200mA, 2A, 3A
Resistance Measurement Range	≤100MΩ
Frequency Measurement Range	3Hz~1.5MHz
Trigger Method	Auto trigger (software trigger), upgradable to bus trigger
Maximum Non-Destructive Voltage	350VRMS

Software Interface

The DMM4365 offers an interactive software panel enabling fast measurements and meeting various application requirements.
